Sunboost is a high-tech enterprise focusing on the R&D, manufacturing and sales of energy storage battery and solar power inverter.
Home Energy Storage System Manufacturers - - Sunboost-1
Products Advantages
- Unshakable Safety and Rock-Solid Stabil-ity , module-pack-system, triple protection.
- Built- in power distri bution box,one-stop solution for wiring and switching.
- Plug and play design : easy installation, time, space and costsaving.
- The perfect combination of inverter and battery.
- Mobile APP Monitoring, control anywhere with our app and cloud platform.
- High-end light luxury style, perfectly suits the European markets.
Product Specifications
| MODEL | TH-51200-SP | ||
| Nominal DC Voltage | 51.2V | ||
| Battery Capacity | 200Ah | 400Ah(200Ah*2) | |
| Energy(KWh) | 10.24KWh | 20.48KWh | |
| Maximum Discharging Current | 120A | ||
| Cycle Life | 6000Cycles(80%DOD) | ||
| Certification | UN38.3, MSDS, CE-EMC, IEC62619, UL1973 | ||
| Environment humidity | 0-95% | ||
| Dimensions(H*W*D)mm | 1300*620*212mm | 1895*620*212mm | |
| Net Weight(kg) | 120KG | 220KG | |
| Communication method | WIFI/4G | ||
| Grid connection certification | EN50549- 1, EN50549- 10, PTPiREE, NCRFG, VDE4105, AS/NZS4777.2, NRS-097-2- 1 | ||
| All in One ESS series-TG-ESS | |||
| MODEL | TG-HYB-5000 | TG-HYB-6000 | |
| PV INPUT(DC) | |||
| Recommend max.PVi nput power 10000Wp | 11000Wp | ||
| Max.PV input voltage | 600V | ||
| Min.operation/Start-up Voltage | 40V/50V | ||
| Rated PV input voltage | 360V | ||
| MPPT Voltage Range | 40-560V | ||
| No.of independent MPPT inputs | 2 | ||
| Max.PV input current | 16A | ||
| Max.DCs hort-circuit current | 20A | ||
| INPUT/OUTPUT(AC) | |||
| Max.AC input power from grid | 10000VA | 11000VA | |
| Rated AC output power | 5000W | 6000W | |
| Rated AC output current (at 230V) | 21.8A | 26. 1A | |
| Rated AC voltage | 220V/230V/240V | ||
| AC voltage range | 154V~276V | ||
| Rated grid frequency | 50Hz/60Hz | ||
| Grid frequency range | 45~55Hz/55~65Hz | ||
| EFFICIENCY | |||
| Max.efficiency | 97.70% | ||
| European efficiency | 97.30% | ||
| PROTECTION&FUNCTION | Grid monitoring/DC reverse polarity protection/AC short circuit protection/Leakage current protection /DCswitch(PV)/DC fuse(battery)/Battery input reverse polarity protection | ||
| SurgeProtection | DC typeⅡ/AC typeⅡ | ||
| BATTERY DATA | |||
| Battery Type | Li-ion battery | ||
| Battery voltage | 40-59V | ||
| Max.charge/discharge current | 100A | ||
| Max.charge/discharge power | 5000W | ||
| GENERAL DATA | |||
| Dimensions(W*H*D) | 600*365*180mm | ||
| Weight | ≤25kg | ||
| Degree of protection | IP65 | ||
| BACKUP DATA(ONGRIDMODEL) | |||
| Rated | output power for backup load | 6000W | |
| Rated | output current for backup load | 27A | |
| BACKUP DATA(OFF GRID MODEL) | |||
| Rated voltage | 220V/230V/240V(±2%) | ||
| Frequency range | 50Hz/60Hz(±0.5%) | ||
| Switch time to emergency model | ≤10ms | ||
| Rated output power | 5000W/5000VA | 6000W/6000VA | |
| Peak output power | 8400VA, 10s | ||
| Certifications and Standards | |||
| Grid Regulation | EN50549- 1, EN50549- 10, PTPiREE, NCRFG, VDE4105, AS/NZS4777.2, NRS-097-2- 1 | ||
| Safety Regulation | IEC62109- 1&2, EN62109- 1&2 | ||
| EMC | EN61000-6- 1, EN61000-6-3, IEC61000-6- 1, IEC61000-6-3 | ||
Company Advantages
· Our home energy storage system manufacturers has its own style than other products thanks to the support of our excellent staff.
· home energy storage system manufacturers can ensure good performance and value, and give full play to a certain role.
· Our offered product is widely applauded by our clients due to its incomparable features.
Company Features
· As a high tech company, Sunboost Technology Co.Ltd is mainly devoted to the research and development and manufacturing of home energy storage system manufacturers.
· Aside from our major presence in China, we have already expanded markets in the United States, Germany, Japan, etc. Our R&D team is working hard to create products including home energy storage system manufacturers that cater to more countries.
· Sunboost Technology Co.Ltd only produce high class cases for the customers. Contact us!
Application of the Product
The home energy storage system manufacturers developed by our company can play a role in various fields.
Since the establishment, Sunboost has always been focusing on the R&D and production of Home storage battery,Commercial & Industrial storage battery,hybrid solar inverter. With strong production strength, we can provide customers with personalized solutions according to customers' needs.
