Sunboost is a high-tech enterprise focusing on the R&D, manufacturing and sales of energy storage battery and solar power inverter.
OEM Solar Inverter Wholesale Suppliers Sunboost
Company Advantages
· Innovative design concept: From appearance to construction, Sunboost solar inverter wholesale suppliers is designed by our professional designers. They discuss to each other to ensure that each design has the innovative characteristics of industrial standard.
· The product is highly reliable in performance and can be used for a long period.
· Sunboost Technology Co.Ltd has won wide market for solar inverter wholesale suppliers by virtue of high quality.
Products Advantages
4- 10kw available.
Full protection: With overload, over tempera-ture, short circuit protection.
UPS Mode: Seamless transition to backup mode to assure an uninterrupted powersupply.
Pure sine Wave Inverter (off-grid)
Wide applications: Can power a variety of applianc-es in your home or office environment, including tube lights, fans, refrigerators, and air conditioners.
Product Specifications
| TG-HVB 4- 10KW Single Phase OFF Grid Inverter | |||||||||||
| MODEL | TGPFG-4KW TGPFG-6KW TGPGF-7KW TGPGF-8KW TGPGF- 10KW | ||||||||||
| PV INPUT(DC) | |||||||||||
| Recommend max.PV input power | 6200W 6500W 7000W 8000W 10000W | ||||||||||
| Nominal DC Voltage/Maximum DC Voltage | 360VDC/500VDC | ||||||||||
| Start-up Voltage/lnitial Feeding Voltage | 60VDC/90VDC | ||||||||||
| MPPT Voltage Range | 60-450VDC | ||||||||||
| Number of MPPT Trackers/ Maximum In put Current | 1/23A 1/27A | ||||||||||
| TWO LOAD OUTPUT POWER | |||||||||||
| FullLoad | 3600W | 6000W | 7000W | 8000W | 1 oooow | ||||||
| Maximum Main Load | 3600W | 6000W | 7000W | 8000W | 10OOOW | ||||||
| Maximum Second Load(battery mode) | 1200W | 2000W | 2400W | 2733W | 3400W | ||||||
| Main Load Cut Off Voltage | 22VDC | 44VDC | |||||||||
| Main Load Return Voltage | 26VDC | 52VDC | |||||||||
| GRID OUTPUT(AC) | |||||||||||
| Nominal Output Voltage | 220/230/240VAC | ||||||||||
| Output Voltage Range | 1 95.5-253VAC | ||||||||||
| Nominal Output Current | 15.7A 27.OA 31.3A 35.6A 44.3A | ||||||||||
| Power Factor | >0.99 | ||||||||||
| Feed-in Grid Frequency Range | 49-51 ±1 Hz | ||||||||||
| Maximum Conversion Efficiency(SloartoAC) | 98% | ||||||||||
| AC INPUT | |||||||||||
| AC Start-up Voltage/Auto Restart Voltage | 120-140VAC/180VAC | ||||||||||
| Acceptable Input Voltage Range | 90-280VACor1 70-280VAC | ||||||||||
| Maximum AC Input Current | 40A 50A 40A 40A 50A | ||||||||||
| Nominal operating frequency | 50/60HZ | ||||||||||
| Surge power | 7200W 10000W 14400W 16400W 20400W | ||||||||||
| BATTERY MODE OUTPUT(AC) | |||||||||||
| Nominal Output Voltage | 220/230/240VAC | ||||||||||
| Output Waveform | Puresinewave | ||||||||||
| Efficiency(DC to AC) | 94% | ||||||||||
| Nominal DC Voltage | 24V 48V | ||||||||||
| Maximum Charging Current (Solar to AC) | 120A | 140A | 160A | 160A | |||||||
| Maximum AC Charging Current | 100A | 120A | 140A | 140A | |||||||
| AC INPUT | |||||||||||
| Dimension,D*W*H(mm) | 420*310*110 | ||||||||||
| Cartoon Dimension,D*W*H(mm) | 500*415*1 80 588*463*205 | ||||||||||
| Net Weight(kgs) | 8.8 | 9.8 | 13.1 | 14.2 | 14.5 | ||||||
| Gross Weight(kgs) | 10 | 11 | 14.1 | 15.7 | 16 | ||||||
| CommunicationPort | RS232/WIFI/GPRS/LITHIUMBATTERY | ||||||||||
Company Features
· Sunboost Technology Co.Ltd is professional in manufacturing reliable solar inverter wholesale suppliers.
· Sunboost Technology Co.Ltd has been very famous for its high quality solar inverter wholesale suppliers. Except the technicians, sales team and service team, we also have QC department equipped to check the quality of solar inverter wholesale suppliers. To be more competitive, Sunboost has introduced advanced technology to produce solar inverter wholesale suppliers.
· Currently, we have made a business goal, that is, to improve brand influence worldwide. We will boost our image by offering high-quality products and made them known to more people.
Product Comparison
Compared with similar products, our company's solar inverter wholesale suppliers has the following outstanding features.
