Sunboost is a high-tech enterprise focusing on the R&D, manufacturing and sales of energy storage battery and solar power inverter.

 sales@sun-boost.com+86-137 6041 3751

Server Rack Batteries Sunboost 1
Server Rack Batteries Sunboost 2
Server Rack Batteries Sunboost 3
Server Rack Batteries Sunboost 1
Server Rack Batteries Sunboost 2
Server Rack Batteries Sunboost 3

Server Rack Batteries Sunboost

Inquiry
Send your inquiry

Products Advantages

Popular Product: Hot sale with 70,000+ unit s sold.

Authoritative Certification: I EC62619, CE - EMC, UL1973

Cost Advantage:Utilizing annual procure- ment and own factory casing production for cost advantages.

Proven Performance: Over 5 years of usage validation with excellent operation, saf ty, stability, and reliability

Multiple Choice: Avarity of design are avail-able for selection

Compact Design: 3U standard size, save shipping cost and installation space for end customer

储能 3-5 拷贝

Product Specifications

Model TH-51100R-Plus
Nominal Voltage 51.2V
Cell model/Configuration 3.2V 100Ah(ANC)/16S1P
Capacity(Ah) 100AH
Rated Energy(KWH) 5.12KWH
Max.Charge/Discharge Current(A) 50A/100A
Voltage Range{Vdc) 43.2-58.4V
Communieation RS232-PC,RS485(B)-BAT RS485(A)-lnverter, Canbus-lnverter
Cycle Life ≥6000 cycles@25°C , 80% DOD , 60%EOL
Design Life ≥15Years(25°C )
Weight(Approx) (KG) 48kg
Dimension (W/D/H)(mm) 483*480*133mm
Installation Mode Rack
IP Grade IP21
Safety(Pack) UN38.3, MSDS, IEC62619, CE-EMC, UL1973
Safety(Cell) UN38.3, MSDS, IEC62619, CE, UL1973, UL2054
Protection BMS, Breaker
Operating Temperature(°C ) Charge:0°C~50°C ; Discharge : -20°C~50°C
储能 301 (2)
NO Item description 9 MC8 DC output
1 Rack mountear for battery pack mounting 10 RUN RUN LED display
2 Handle Handle for carrier 11 ALM Alarm LED dispiay
3 Battery+ terminal M8 screw 12 SOC Capacity remaining display
4 Resret emergency Resret 13 CANBUS Communication port with inverter
5 ADS battery address 14 RS485A Communication port with inverter
6 LCD display battery information 15 RS232 communication port with PC
7 Battery- terminal M8screw 16 RS485B Internal communication between packs
8 GND GND connection for safety 17 ON/OFF Switch ON/OFF battery by soffware

Rack Mounted Battery Series TG-RACK

Download
储能 3-1 拷贝 (2)
储能 3-1 拷贝 (2)
储能 3-4 拷贝 (2)
储能 3-4 拷贝 (2)


Company Advantages

· Sunboost server rack batteries is manufactured from materials that are sourced from reliable suppliers.

· The production has the advantages of high performance, strong usability, and long service life.

· Sunboost Technology Co.Ltd aims to provide clients with competitively priced server rack batteries.


Company Features

· Sunboost Technology Co.Ltd stands at forefront in the market of server rack batteries.

· Sunboost Technology Co.Ltd has established long-term technical cooperation with several universities.

· Sunboost Technology Co.Ltd provides high-quality server rack batteries for a number of world-famous brands.


Application of the Product

The server rack batteries produced by Sunboost is widely used in field for its excellent quality.

Sunboost is committed to providing customers with high-quality Home storage battery,Commercial & Industrial storage battery,hybrid solar inverter as well as one-stop, comprehensive and efficient solutions.
