Company Advantages
· server rack batteri is of exquisite workmanship and unique shape.
· The product meets with the most demanding requirements in all respects of performance, durability, usability, etc.
· The product meets customer expectations and is now popular in the industry with broad market prospects.
Products Advantages
- Stable Performance: Work smoothly
- Rainproof Protection: IP65, indoor and outdo or application.
- Compatible: Compatible with multiple mainstream inverter brands.
- Convenient: Stackable & compact design, easy installation.
- Scalable: Parallel connection available, supports expansion up to 100 kWh.
- High Efficiency: Use of Series connection, voltage range from 204.8V ( 2 module) to 512V(5module)
Product Specifications
| HVStack Battery Series-TG-SS-HV | ||||
| MODEL | TH-20450-SP | TH-30750-SP TH-40950-SP | TH-51250-SP | |
| Nominal Voltage | 204.8V(64series) | 307.2V(96series) 409.6V(128series) | 512V(160series) | |
| CellModel/Configuration | 3.2V50Ah(ANC)32S1P/102.4V50Ah/5. 12KWh | |||
| Capacity(Ah) | 50AH | |||
| Rated Energy(KWH) | 10.24KWh | 15.36KWh | 20.48KWh | 25.6KWh |
| Max.Charge/DischargeCurrant(A) | 25A/50A | |||
| Voltage Range(Vdc) | 172.8-224V | 259.2-336V 345.6-448V | 432-560V | |
| Stackability | Upto5series | |||
| Communication | RS232-PC, RS485-Inverter, Canbus-Inverter | |||
| Cycle Life | ≥6000cycles@25°C, 80%DOD, 60%EOL | |||
| Design Life | ≥15Years(25°C) | |||
| Weight(Approx)(KG) | Approx:130kg | Approx:180kg | Approx:230kg | Approx:280kg |
| Dimension(WxDxH)(mm) | 636*185*1065mm | 636*185*1418mm | 636*185*1770mm | 636*185*2122mm |
| IP Grade | IP65 | |||
| Safety (Pack) | UN38.3, MSDS, IEC62619(CB), CE-EMC | |||
| Satety(Cell) | UN38.3, MSDS, IEC62619, CE, UL1973, UL2054 | |||
| Protection | BMS, Breaker | |||
| OperatingTemperature(°C) | Charge:0℃~50℃; Discharge:-20℃~50℃ | |||
Company Features
· Sunboost Technology Co.Ltd is an experienced manufacturer that produces server rack batteri and other products based on in-depth research on the industry.
· Our plant is home to state-of-the-art machinery, including 3D design and CNC machines. This enables us to use the very latest manufacturing techniques to provide the best quality product.
· We minimize and recycle waste during our operation. We strive to reduce the production waste and have an ultimate goal of zero waste.
Product Details
With the dedication to pursue excellence, Sunboost strives for perfection in every detail.
Product Comparison
Sunboost's server rack batteri has better performances, as shown below.
