Sunboost is a high-tech enterprise focusing on the R&D, manufacturing and sales of energy storage battery and solar power inverter.
Sunboost Solar Inverter Companies Solar Inverter Companiesfactory Price
Company Advantages
· All raw materials of Sunboost solar inverter companies are subjected to intense controls.
· This product has obtained international quality certificates such as ISO9001.
· Due to the wide sales network of Sunboost, the solar inverter companies has gained its popularity all over the world.
Products Advantages
- Pure sine wave inverter
- WIFI&GPRS available for IOS and android
- Built-in 80A MPPT solar charge
- Built-in anti-dusk kit for harsh environment(optional)
- Compatible with lithium-ion battery
- High PV input voltage range (90~450VDC)
- Smart battery charge design to optimize battery life
- Support working without battery
- Compatible to main voltage or generator.
- Battery equalization function to optimize battery performance and extend life cycle
Product Specifications
|
AC Voltage Regulation (Batt.Mode) |
230VAC±5% |
|
|
Surge power |
3000VA |
4800VA |
|
Transfer Time |
10ms (for personal computers)20ms (for home appliances) |
|
|
Wave form |
Pure Sine Wave |
|
|
BATTERY & AC CHARGER |
||
|
Battery Voltage |
12VDC |
24VDC |
|
Floating Charge Voltage |
13.5VDC |
27VDC |
|
Overcharge Protection |
15.5VDC |
31VDC |
|
Maximum charge current |
60A |
|
|
SOLAR CHARGER |
||
|
MAX.PV Array Power |
2000W |
3000W |
|
MPPTRange@Operating Voltage |
90-450VDC |
|
|
Maximum PV Array Open Circuit Voltage |
450VDC |
|
|
Maximum Charging Current |
80A |
|
|
Maximum Efficiency |
98% |
|
|
PHYSICAL |
||
|
Dimension.D*W*H(mm) |
348*270*95mm |
470x305x125mm |
|
Net Weight (kgs) |
4.0kg |
5.0kg |
|
Communication Interface |
RS232(Standard) GPRS/WIFI(Optional) |
|
|
OPERATING ENVIRONMENT |
||
|
Humidity |
5% to 95% Relative Humidity(Non-condensing) |
|
|
Operating Temperature |
- 10°C to 50°C |
|
|
Storage Temperature |
-15°C to 60°C |
|
Company Features
· Focusing on the R&D, manufacturing and sales of solar inverter companies, Sunboost Technology Co.Ltd has its own R&D and production base.
· Our design team is highly talented to bring out the best designs. They work hard in an iterative way, constantly evolving and refining to ensure we create a design that exceeds both customers' needs and expectations.
· Innovation is deeply rooted in the company's culture.
Application of the Product
Our solar inverter companies is widely used in industry.
From the customer's point of view, we provide our customers with a complete, fast, efficient and feasible solution to solve their problems.
